RV Rotary Vane
Rugged pump with extreme vacuum and process performance
0.002 mbar
Excellent vacuum levels even with Gas Ballast
EXTREME VAPOUR HANDLING
Through a unique combination of Gas Ballast and Dual-mode
< 48 dB(A)
Very quiet operation for a better work environment
ATEX & FOMBLIN
Atex and Fomblin versions also available
The Rv Series Is The World's Standard For Oil-lubricated Rotary-vane Laboratory Vacuum Pumps. It Is Considered As The Most Rugged And Best Performing Pump In It's Class, And Is Still Today The Undisputed Leader In It's Industry.
RV Rotary Vane Pumps
|
|
|
|
||
| RV3 | RV5 | RV8 | RV12 | ||
| Peak pumping speed | m³/h | 3.3 | 5.1 | 8.5 | 12 |
| Ultimate vacuum | mbar | 0.002 | 0.002 | 0.002 | 0.002 |
| Ultimate vacuum with gas ballast | mbar | 0.03 | 0.03 | 0.03 | 0.03 |
| Water vapour handling capacity | g/h | 220 | 220 | 220 | 290 |
| Noise at ultimate | dBA | 48 | 48 | 48 | 48 |
RV oil sealed pumps have been the industry standard rotary vane pump for laboratory applications for many years thanks to design features that make them low cost to operate and maintain versus other rotary pumps.
With their unique mode selector, one pump can be used for both high throughput and high vacuum applications; selfcentring mechanism, no dowels to set and can replace any component; high vapour pumping capability and broad range of accessories makes RV pumps the best long term proposition for laboratory applications.
Product Features
FAST-ACTING INLET VALVE
for pump isolation in case of electrical or power failureHIGH GAS BALLAST FLOW RATE
for up to 220 gh⁻¹ water vapour pumping capacityEASY MAINTENANCE
self-aligning parts, no special tools requiredHIGH QUALITY OILS
longer lasting with special additives to prolong life whilst not impacting vapour pressureLOW NOISE
at just 48 dB(A)UNIQUE MODE SELECTOR SWITCH
enables high vacuum and high throughput operation from a single pump
